TeSys LR9F electronic overload relay, thermal setting range 30-50A, class 10, for protection of motors 18.5-22kW@400V. to be mounted directly below a TeSys F 3-pole contactor LC1 F115, F150, F185, use of a support mounting plate LA7F901 is recommended (to be ordered separately). Motor protection includes thermal overload of 1-phase and 3-phase motors, phase failure, phase unbalance, prolonged starting times, stalled rotor conditions. On the front of the relay, it provides a thermal adjustement dial, buttons for test, stop & reset, a trip indicator, trip auxiliary contacts 1NO+1NC. Multi standards certified (IEC, UL, CSA, CCC, Marine), Green Premium compliant (RoHs/Reach).
User Manual:
Schneider Electric_TeSys-LR9-Overload-Relays_LR9F5357
Schneider Electric_TeSys-LR9-Overload-Relays_LR9F5363
Schneider Electric_TeSys-LR9-Overload-Relays_LR9F5367
Schneider Electric_TeSys-LR9-Overload-Relays_LR9F5369
Schneider Electric_TeSys-LR9-Overload-Relays_LR9F5371
Schneider Electric_TeSys-LR9-Overload-Relays_LR9F7375
